Galaxy 4 color vinyl sticker printer with DX5 head

FOB Reference Price:Get Latest Price
$3,500.00 - $7,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Color & Page:
Multicolor
Gross Power:
1300w
Certification:
CE Cetification
Usage:
Large format advertisment printing
Plate Type:
Screen Printer
Type:
Inkjet Printer
Condition:
New
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Galaxy
Model Number:
UD-161LC
Automatic Grade:
Automatic
Voltage:
AC110v, 50HZ/60HZ
Dimensions(L*W*H):
2860mm*1050mm*685mm
Weight:
377kg
color:C/Y/M/K:
Warranty: one year
speedy:33sqm/h:
printhead:1PC DX5 head
RIP software:Maintop or Photoprint:
media type: Vinyl,Polyester,Flex,Back-lit Film,PS board,KT board
available size: 1.6m:
printhead height ( adjustable ): above media adjustable
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Plywood,standard for export
Port
HuangPu(gunagzhou) or Shenzhen



Our Services

 1,Big Discount!Best quality and after-service.

 2,Welcome to jion our working team ,you will find that we are the same channel !!

We will provide you

1, One year warranty                2, English RIP and Promon printingsoftware
3,Online trainning support        4, Big Discount and patient friendly service


Product Description

Galaxy 4 color vinyl sticker printer with DX5 head









1,Can print both roll to roll printing media and work with flatbed ,print directly on PS and KT board

2 , Work  with one DX5 head

3,1440dpi High resolution, CMYK 4 color printing

4, Suitable for both indoor and outdoor printing



Galaxy 4 color vinyl sticker printer with DX5 head showed in Exhibition

Galaxy 4 color vinyl sticker printer with DX5 head in customer's printing room

The Application from galaxy 4 color vinyl sticker printer with dx5 head


Tichnical data of galaxy 4 color vinyl sticker printer with dx5 head

MODEL

UD-161LC

Printhead

DX5

Number of printhead

1 Head

Maximum print width

1,600mm

Print Speed (m2/h)

Print mode

Standard output(m2/h)

RD

2 PASS 29

D

3 PASS 19

S

4 PASS 14

Q

6 PASS 9

HQ

8 PASS 7

BL

12 PASS 4

Ink

Type:

Water based / Eco Solvent Ink

Color :

4 Color (C,M,Y,K)

Capacity:

1L per Main Tank of Each Color

Ink Supply System

Auto Ink Supply System

Media Width

Maximum 1,680mm



Media Type

Vinyl, Polyester, Flex, Back-lit Film, PS Board, KT Board, PVC Board, etc.

Auto Media Feeding System

Equipped (Max. Media Weight 25kg)

Auto Cleaning System

Anti-clogged Flash Function & Capping System

Pre-heating & Drying System

Equipped

Clamp

Equipped

Print Interface

USB 2.0

Printhead Height

2 to 6 mm from Media

RIP Software

Ultraprint, Maintop, Photoprint, Wasatch, Ergosoft

Input Power

AC 220V, 50Hz/60Hz

Machine Dimension / N.W

L2,820 x W990 x H1,260mm / 200KG

Package Dimension / G.W

L2,860 x W1,050 x H685mm / 377KG

Packaging & Shipping



 Export much container galaxy 4 color vinyl sticker printer with dx5 head to oversea
